TecNiq S90 Mini LED Side Marker Light, Red/Amber Bi-Color Fender Light with 9" Pigtail,S90-0000-1

$15.48 USD

Shipping calculated at checkout.

Quantity

Pack of 2 Pack of 4 Pack of 8

Product variants

Care information

To ensure optimal performance and extend the service life of your new trailer components, please follow these care guidelines after purchase:

Before installation, check all parts for shipping damage or missing components. Do not install damaged parts.
Always use correct tools and torque settings. Improper installation can lead to premature wear or failure.
For bearings, suspensions, and brake components, apply high-quality trailer grease before first use if not pre-greased.
Some parts (like brake assemblies) require a short break-in period to achieve full performance. Follow manufacturer instructions for best results.
Recheck fasteners, grease levels, and moving components after 100 miles of towing, then at regular intervals.
After exposure to water, road salt, or mud, clean and dry parts thoroughly. Apply anti-rust treatment if needed.
If storing unused parts, keep them in a dry, sealed container away from moisture and direct sunlight.

Delivery and Shipping

Handling Time: Orders ship out within 1 business day after payment is received.

Shipping Methods: We use trusted carriers like UPS, FedEx, or USPS based on package size and destination.

Delivery Time: Estimated delivery within 2–6 business days (U.S. domestic orders).

Tracking: A tracking number will be provided once your order is dispatched.

Q1 Will this brake fit my trailer?

This brake assembly fits most standard 7,000 lb trailer axles that use 12" × 2" electric brakes with a 5-bolt mounting flange. Please verify your axle rating and brake dimensions before ordering. If you're unsure, send us your axle tag or hub information and we'll help confirm compatibility.

Q2 Does it fit Dexter or Lippert axles?

Yes. It is compatible with many standard Dexter, Lippert, Rockwell American, AL-KO, and other 7,000 lb trailer axles that use a standard 12" × 2" brake assembly. Always verify your axle specifications before purchasing.

Q3 Is this a self-adjusting brake?

Yes. This is a self-adjusting electric brake assembly, which automatically maintains proper brake shoe clearance during normal operation. This reduces maintenance and helps provide consistent braking performance.

PRODUCT OVERVIEW:

Significantly maximize your transport security and ensure absolute highway compliance with this premium S90 heavy duty miniature bi-color fender light expertly engineered by TecNiq Inc. As a market-leading lighting solution, this model combines an amber and red LED to meet the furthest extent clearance requirement of trailers. The brilliant output of these lamps will assure your customers that there is no mistaking the quality and safety of your designs. Featuring a low profile design, the structural assembly is equipped with TecSeal urethane potting to guarantee circuit board protection, making it completely submersible and IP68 rated dust and water proof. The durable impact resistant lens is constructed from premium automotive exterior lighting grade polycarbonate to ensure excellent long term UV resistance. Engineered to deliver reliable performance over one hundred thousand hours, this high performance vehicle indicator satisfies dual intensity operational needs. This specific model S90-0000-1 is configured as a fender sidemarker light with a standard pigtail nine inch connection layout to provide optimal vehicle retrofitting flexibility.

WHATS INCLUDED:

1 x TecNiq S90-0000-1 Fender Sidemarker Light Assembly

SPECIFICATIONS:

Brand: TecNiq Inc

Product type: Fender Sidemarker Light

Part number: S90-0000-1

Product dimensions: 1.5" x 0.8"

Technical diagram clearance dimensions: 0.75" Width by 1" Hole spacing by 1.5" Base width and 0.79" Height engineering layout sizes

Illumination output color: Red/Amber bi-color combination

Internal lighting component: 2 LEDs

Lens styling appearance: Low profile design with durable impact resistant lens

Lens material: Automotive exterior lighting grade polycarbonate with excellent UV resistance

Illumination coverage rating: Meets the furthest extent clearance requirement of trailers

Voltage: 9-14VDC

Current: 0.04A-0.07A

Ingress protection rating: IP68 Rated - Dust and water proof with completely submersible capabilities

Sealing technology: TecSeal Urethane Potting - Guaranteed Circuit Board Protection

Regulatory compliance: Exceeds FMVSS 108 standards

Connectors: 9" pigtail standard configuration with Pigtail (9") infrastructure listing

Technical feature wire colors definition: White indicates Ground, Red indicates Positive, Black indicates Low dual intensity

Standard Model wire configuration: White Wire - Ground, Red Wire - 12VDC Power

Dual Intensity Model wire configuration: White Wire - Ground, Red Wire - High Intensity, Black Wire - Low Intensity

Ground: White grounding interface system layout

Mounting configuration: Surface-mounted with 1" hole spacing setup with see download for wire guide and cover reference guidelines

Operational lifespan longevity: Reliable performance over 100,000 hours
