LED Trailer Light & Wiring Kit - 6" Oval Tail Lights, Side...
Product Description:
Refresh your trailer's lighting with this RGP-assembled bundle featuring JAMMY LED tail lights, amber and red side markets, a TecNiq license plate light, adhesive reflectors and a 25-foot 4-way flat wiring harness.
The two 6" oval rear lamps provide stop, turn and tail functions. Each include a matching rubber mounting grommet and PL-3 pigtail. Four compact 3/4" LED market lights provide amber and red side lighting, while the chrome-housing license plate lamp illuminates the trailer's plate.
The included amber and red reflectors add passive visibility without electrical connections. A JAMMY 4-way flat harness supplies the lighting circuits for installation or rewiring.
This bundle is suitable for trailer lighting projects with compatible mounting locations and a 12V electrical system. Installation requires wiring connections, proper grounding and verification that the supplied components meet the trailer's lighting layout.
Specifications:
Bundle assembled by : Running Gear Parts
Components brands: JAMMY and TecNiq
Electrical system: 12V DC
Powered lamps included: 7
Rear tail lamps: Two 6" oval LED lamps with red lenses
Rear lamp functions: Stop, turn and tail
Tail lamp mounting: Rubber grommet mount
Tail lamp connections: PL-3 pigtails
Marker lamps: Two amber and two red 3/4" LED lights
Marker mounting: Rubber grommets
Marker leads: 9" hardware leads
License plate lamp: TecNiq L11-WC00-1, chrome-plated housing
License lamp mounting: Vertical surface mount, 2“ screw spacing
Harness connector: 4-way flat
Harness lighting-wire length: 25 feet
Harness ground-wire length: 30 inches
Reflectors: Two amber and four red
Reflector dimensions: 3-1/4" x 1-3/16"
Reflector mounting: Self-adhesive
What's Included by Kit Option:
2 × Jammy J-66 red 6″ oval LED stop/turn/tail lamps
2 × Jammy J-60-GM tail lamp mounting grommets
2 × Jammy J-60-WH PL-3 tail lamp wiring pigtails
2 × Jammy J-51-A amber 3/4″ LED marker lights
2 × Jammy J-51-R red 3/4″ LED marker lights
4 × Jammy J-54-GM marker light mounting grommets
1 × TecNiq L11-WC00-1 LED license plate light with attached lead
1 × Jammy J-5024-WH 25′ 4-way flat trailer wiring harness
2 × Jammy J-002-A adhesive amber reflectors
4 × Jammy J-002-R adhesive red reflectors
Installation & Fitment
Confirm the trailer’s dimensions, lighting locations, mounting openings and required wire routing before ordering. A 25′ harness does not necessarily fit a 25′ trailer because installation routing consumes additional length.
Splice connectors, additional ground wire, mounting screws, license plate bracket, lamp mounting brackets, wire loom and cable ties are not included.
The 4-way harness supports trailer lighting circuits; it does not provide electric brake, auxiliary power or reverse-light circuits. Additional lighting may be required for the trailer’s width, length and configuration.
